CJPJ/NC CJPF/NC船用电缆系列
CJPJ/NC CJPF/NC船用电缆系列
0.6/1kV
交联聚乙烯绝缘低烟无卤电力电缆
XLPE insulated halogen-free low-smoke shipboard power calbe
图例 Example:
CJPF86/NC
3X120
型号： CJPJ/NC
Type: CJPJ80/NC
CJPJ90/NC
CJPJ85/NC
CJPJ95/NC
CJPF/NC
CJPF80/NC
CJPF90/NC
CJPF86/NC
CJPF96/NC
用途 Application
船用电力电缆可用于河海种种船舶及海上石油平台等 水上修建的电力照明和一样平常控制装置之用。对冶金、 化工、电力等工矿企业亦同样适用。
The cable is intended for power lighting and control system of shipboard and off-shore building such as oil platform. It is also available to metallurgical industy, chemical works, power plant and corporation mining
etc
结构 Construction
执行标准 Standards applied
IEC 60092-353 IEC 60228 Class2 IEC 60092-351 IEC 60092-359 IEC 60331 IEC 60332-3-22 IEC 60754 IEC 61034 | – 设计 – 导体 – 绝缘 – 护套 – 耐火 – 阻燃 – 无卤 – 低烟 | Design Conductor Insulation Sheath Fire Resistant Flame Retardant Halogen Free Low Smoke |
组分 Components | 代号 Code | 质料/描述 Material/Description |
系列代号 Series code | C | 船用电力电缆 Shipboard power cable |
导体 Conductor | 绞合镀锡退火铜， IEC 60228 Class 2 Stranded tinned annealed copper (STC), IEC 60228 Class 2 | |
绝缘 Insulation | J | 耐火云母带+交联聚乙烯 Mica glass tape + XLPE, IEC 60092-351 |
内护套 Inner sheath | PJ | 无卤阻燃热固性子料 Halogen-free flame retardant thermoset compound (SHF2) |
PF | 无卤阻燃热塑性子料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
铠装 Armor | 8 | 镀锡铜丝编织 Tinned copper wire braid (TCWB) |
9 | 镀锌钢丝编织 Galvanized steel wire braided (GSWB) | |
外护套 Outer sheath | 0 | 无外护套 Without outer sheath |
5 | 无卤阻燃热固性子料 Halogen-free flame retardant thermoset compound (SHF2) | |
6 | 无卤阻燃热塑性子料 Halogen-free flame retardant thermoplastic compound (SHF1) | |
外护套颜色 Outer sheath color | 玄色(若有) Black, if any | |
燃烧特征 Flammability | NC | 低烟无卤耐火 LSHF Fire resistant, IEC60331 |
